The LS-360-BC-30T Ball Capture Load Cell from Liberty Scales is a robust, multi-purpose load cell designed to meet the rigorous demands of industrial weighing applications. With a rated capacity of 30 tons per load cell, this model can handle even the most heavy-duty operations, making it ideal for use in weigh-bridges, truck scales, and railway scales. The kit includes LS-7581-TS indicator, junction box & 30’ Home run cable.

Key Features:

• Rated Capacity: 30 tons per load cell, allowing you to calculate total capacity by multiplying the number of load cells used.
• Accuracy Class: C3,
• - Rated Output: 2.0 ± 0.002 mV/V,
• Total Error: ± 0.02%
• - Creep (30min): ± 0.02%
• Input Resistance: 760 ± 10Ω and
• Output Resistance: 702 ± 2Ω, ensuring electrical consistency.
• Overload Protection: With a safe overload limit of 150% of full scale and a destructive load limit of 300%, it offers reliable protection during heavy use.
• Operating Temperature: Designed to operate in temperatures ranging from -10°C to +40°C, making it suitable for a wide variety of environments.
• Construction: Available in alloy steel

Versatility:

This load cell is engineered to handle extreme weight conditions with 200% overload protection and is ideal for a wide range of applications including weighbridges, truck scales, and railway scales. Its robust design and IP67-rated construction make it reliable in outdoor and industrial environments.

Additional Specifications:

• Excitation: 4~12VDC (Max: 15VDC)
• Cable Length: 8~16m, with 4 wires shielded for protection and optimal signal transmission.
•  Wiring Configuration: Exc+ (red), Exc- (black), Sig+ (green), Sig- (white)

This load cell offers unparalleled accuracy, durability, and overload protection, making it the perfect choice for industrial weighing solutions.
